- Indoor / Outdoor underground, above ground, under water, in cable ducts
- Excellent adhesion on all plastic insulated cables and metal components
- Hot melt coating inside
- Polyolefine crosslinked
- Fast recovery
- Shrink temperature 70°C till 100°C
- Continuous temperature range from -40°C till +100°C
- Good resistance against UV and chemicals
- Corrosion resistant
- Cadnium free and halogen free
- No shelf-life
- Colour: black
Characteristics | Value | Standard |
| Physical | ||
| Tensile Strength | 12 N/mm² (MPA)(min) | ASTM D638 |
| Ultimate Elongation | 350% (Min.) | ASTM D638 |
| Density | 1.05 ± 0.2 gm/cm³ | ASTM D792 |
| Hardness | 45 ± 10 Shore D | ASTM D2240 |
| Water Absorption | 0.2% (max.) | ASTM D570 |
| Thermal | ||
| Accelerated ageing | 120°C for 500 Hrs | ASTM D2671 |
| Tensile Strength | 11 N/mm² (Mpa)(min.) | ASTM D638 |
| Ultimate Elongation | 300% (Min.) | ASTM D638 |
| Low Temperature Flexibility (-40°C for 4 Hrs.) | No Cracking | ASTM D2671 |
| Heat Shock (250°C for 30 Min.) | No Cracking or flowing | ESI 09-11 |
| Shrink Temperature | 125°C | IEC 216 |
| Continuous Temperature Limit | -40°C to +100°C | IEC 216 |
| Electrical | ||
| Dielectric Strength | 12 KV/mm. (Min.) | ASTM D149 |
| Volume Resistivity | 1 x 10¹⁴ Ohm.cm(min.) | ASTM D257 |
| Dielectric Constant | 5 (Max.) | ASTM D150 |
